AMT102-V 48 to 2048 CPR DIP Programmable quadrature encoder

26,51 €
Tasse incluse

Italia

Nexive: per ordini inferiori a 24,98 € il costo é 2,50 € - consegna 7 - 15 gg lavorativi

Nexive: per ordini superiori a 24,99 € la spedizione é Gratis - consegna 7 - 15 gg lavorativi

DHL: per ordini inferiori a 24,98 € il costo é 9,90 € - consegna 2 - 3 gg lavorativi

DHL: per ordini compresi tra 24,99 € e 49,98 € il costo é 7,90 € - consegna 2 - 3 gg lavorativi

DHL: per ordini compresi tra 49,99 € e 98,99 € il costo é 5,90 € - consegna 2 - 3 gg lavorativi

DHL: per ordini superiori a 99 € la spedizione é Gratis - consegna 2 - 3 gg lavorativi

Europa

DHL: costo fisso di 15,99 € per il territorio europeo - consegna in 2 - 3 gg lavorativi

Poste Italiane Registered: peso max 250 gr. - il costo varia tra 7,10 € e 12,70 € - consegna in 2 - 4 settimane.

Resto del mondo

DHL: costo fisso di 39,99 € per il resto del mondo - consegna in 2 - 3 gg lavorativi

Poste Italiane Registered: peso max 250 gr. - il costo varia tra 8,40 € e 16,50 € - consegna in 2 - 4 settimane.

Quantità
Disponibile

10.7210.0007

AMT102-V KIT  28 mm 48 ~ 2048 PPR Incremental Capacitive Modular Encoder




CUI's AMT Series modular encoder has been designed with proprietary, capacitive, code-generating technology and represents a breakthrough in cost vs. resolution.
The AMT102 or AMT103 VersaPak models come standard with an onboard dip switch with 16 selectable resolution options ranging from 48 to 2048 PPR.
They also include an index pulse as a standard feature.
The output is TTL voltage and the operating temperature is -40°C to 100°C.
The AMT is available in two mounting options: AMT102 is radial (straight orientation) and AMT103 is axial (right angle orientation).
With the disk built-in to the top cover, the assembly is very quick and easy.
The assembly involves snapping the shaft adapter over a selected sleeve on the back shaft of a DC motor, aligning and mounting the selected base unit with one of the mounting hole options, and snapping the top cover into place in seconds.
To aid in assembly, all VersaPak models include 9 different color coded sleeves to fit most shaft diameters from 2mm to 8mm plus and two simple mounting tools.
Base plates are pre-drilled with 9 (AMT102) or 7 (AMT103) mounting hole options, including a wide base plate for AMT102 to handle 1.27" or 1.81" bolt circles.

Features

  • 16 programmable resolutions via on-board dip switch
  • Resilient to dirt and dust
  • Straight (radial) and right-angle (axial) connection types
  • 9 different shaft sizes from 2 mm to 8 mm
  • -40 ~ +100° C temperature range

Specifications

Input Voltage (Vdc) 3.6 - 5.5 Vdc
Speed, Max. (RPM) 7500
Max Current
10 mA max
Output Type
TTL voltage
Operative Temperature
-40 - 100°C
Resolutions 48, 96, 100, 125, 192,
200, 250, 256, 384, 400,
500, 512, 800, 1000, 1024,
2048 PPR


Optional accessory

Connection Cable 10.8080.0006 - CUI-3132-1FT
