Display LED 4+4 8Segment digit and 8 general porpouse LED ( BVN-S392RG2 )
Display LED 4+4 8Segment digit and 8 general porpouse LED ( BVN-S392RG2 )
€2.38
Tax included
Italy
Nexive: orders below 24,98 € shipping costs is 2,50 € - shipping times of 7 - 15 working days
Nexive: orders above 24,99 € shipping is FREE - shipping times of 7 - 15 working days
DHL: orders of less than euro 24,98 € shipping costs is 9,90 € - shipping times of 2 - 3 working days
DHL: orders between 24,99 € and 49,98 € shipping costs is 7,90 € - shipping times of 2 - 3 working days
DHL: orders between 49,99 € and 98,99 € shipping costs is 5,90 € - shipping times of 2 - 3 working days
DHL: orders above 99 € shipping is FREE - shipping times of 2 - 3 working days
Europe
DHL: fixed cost of euro 15,99 € for the whole European territory - shipping times of 2 - 3 working days
Poste Italiane Registered: 250 gr. max weight limit and the cost varies from 7,10 € to 12,70 € - shipping times of 2 - 4 weeks.
Rest of the World
DHL: fixed cost of 39,99 € for the rest of the world - shipping times of 2 - 3 working days
Poste Italiane Registered: 250 gr. max weight limit and the cost varies from 8,40 € to 16,50 € - shipping times of 2 - 4 weeks.
Display LED 4+4 8Segment digit and 8 general porpouse LED ( BVN-S392RG2 )
Total Rating
Buying this product you will collect 20 points with our loyalty program. Your can convert 20 points in your account into a voucher for a future purchase.
SOFTWARE:
See TM1638 GithHub library made by MrLoba81 for BVN-S392RG2 : GET LIBRARY
DESCRIPTION
Dice Material : (R)GaAlAs/GaAs,DH Super Brightness Red (G) AlGaInP/GaAs Green
Light Color : (R)Red Color (G) Green Color
Lens Color : Milky Diffused
Surface Color : Gray
BVN-S392RG2 ABSOLUTE MAXIMUM RATINGS ( Ta = 25 ℃ )
| PARAMETER | RED | GREEN | UNIT |
| Power Dissipation (PD) | 60 | 65 | mW |
| Continuous Forward Current (IF) | 25 | 25 | mA |
| Peak Forward Current ( 1/10 Duty Cycle , 0.1ms Pulse Width ) | 90 | 90 | mA |
| Reverse Voltage (VR) | 5 | 5 | V |
| Derating Linear From 25 ℃ | 0.33 | 0.33 | mA/°C |
| Operating Temperature Range (Topr) | －35 ℃ to ＋ 75 ℃ | ||
| Storage Temperature Range (Tstg) | －35 ℃ to ＋ 85 ℃ | ||
| Lead Solder Temperature 1.6 mm Below Package 260 ℃ for 5 seconds (Tsld) |
BVN-S392RG2 ELECTRICAL / OPTICAL CHARACTERISTICS (Ta = 25 ℃)
| RED | GREEN | ||||||||
| SYMBOL | PARAMETER | TEST COND. | MIN. | TYP. | MAX. | MIN. | TYP. | MAX. | UNIT |
| Vf | Forward Voltage | I F = 20 mA | 1.8 | 2.4 | 2.1 | 2.6 | V | ||
| Ir | Reverse Current | Vr=5V | 100 | 100 | μA | ||||
| λp | Peak Emission Wavelength | I F = 20 mA | 660 | 572 | nm | ||||
| λd | Dominant Wavelength | I F = 20 mA | 643 | 571 | nm | ||||
| I V | Luminous Intensity | I F = 10 mA | 13 | 23 | 17 | 30 | mcd |
